2-36 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
FWD/REV CONTROLS - PARTS LIST
Key No. Part Number Description Qty.
1 7-30-05108 Guard - Upper Belt 1
2 7-03-04201 Arm - Weldment - Pump Control 1
3 2-00-00729 Key 1/8 x 5/8 (#5) Woodreff 1
4 8-16-00063 Centering Control 1
5 7-25-02050 Rod End, Spherco 2
6 8-66-00162 Rod - Brake Pull 1
7 2-95-01999 Nut, 1/4-28 Hex Jam 3
8 2-00-05261 Threaded Insert - 1/4-20 3
9 7-58-05303 Weldment - Foot Plate 1
10 7-55-00030 Pedal, FWD/REV 1
11 7-66-00197 ¼-20 Male Rod End 1
12 7-66-00194 Rod-Hydro Back 1
13 7-09-00148 Bushing - Flanged P/M Bushing 2
14 7-09-00149 Bushing 2
15 7-76-00123 Spring 2
16 7-82-00045 Switch - Proximity (Normally Open) 2
HARDWARE USED:
H15 2-00-00221 Screw, 1/4-20 x .750 HHC 3
H24 2-00-00220 Screw, 1/4-20 x .625 HHC 2
H26 2-00-00641 Nut, 1/4-20 Insert Fiber 1
H72 2-00-00518 Lock Washer, Helical Spring 3
H114 2-00-00633 Nut, Fiber ¼-28 2
H233 2-00-02638 Screw, HHC .25-20 x 3.00 1
H319 2-00-02352 Nut, Hex Hvy. .50-13 stl-zn 1
C1923/0102
