2-38 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
BRAKE ASSEMBLY - PARTS LIST
Key No. Part Number Description Qty.
1 7-55-00029 Brake Pedal Weldment 1
2 7-55-00019-1 Arm - Parking Brake Pedal 1
3 8-09-01069 Bushing - Brake Pedal Lock 1
4 7-76-00013 Spring - Squeegee Release Pedal 1
5 2-00-03635 Pin - Roll 1
6 7-50-05145 Pad - Brake Pedal 1
7 8-13-07067 Clip - Parking Brake 1
8 7-08-02008 Brake Caliper Weldment 2
9 8-14-01006 Clevis 4
10 7-66-00192 Rod - Brake Link 2
11 2-00-04909 Yoke Pin Assembly 4
12 2-00-05249 Hair Pin (Cotter) 4
13 7-76-00051 Spring 2
14 2-95-01999 Nut - 1/4-28 Hex Jam 2
HARDWARE USED:
H17 2-00-00205 Screw, ¼-20 x 1.000 HHC 4
H20 2-00-00203 Screw, ¼-20 x 1.500 HHC 1
H26 2-00-00641 Nut, ¼-20 Insert Fiber 5
H27 2-00-03702 Washer, .625 x .281 x .063 5
H45 2-00-00585 Nut, Hex. 5/16-18 x .500 x .265 2
H46 2-00-00644 Nut, 5/16-18, Insert Stop 4
H69 2-00-01255 Screw, 5/16-18 x .875 HHC Stl 4
H190 2-00-00529 Lock Washer - helical sps, 8 MDM 2
C1930/0007
