2-22 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
REAR SQUEEGEE (40”) - PARTS LIST
Key No. Part Number Description Qty.
1 7-75-01164 Bushing, Spacer 2
2 7-89-08073 Caster 2
3 7-13-07188 Clamp, LH Squeegee End 1
4 7-13-07156 Clamp, Nut 2
5 7-13-07187 Clamp, RH Squeegee End 1
6 7-20-06010 Duct - Squeegee Inlet 1
7 7-39-00026 Knob, Squeegee 4
8 2-00-04962 O-Ring, Seal 2
9 7-77-00110 Squeegee, Rubber Inner 1
10 7-75-01188 Spacer - Squeegee 2
11 7-77-00109 Squeegee, Rubber Outer 1
12 7-86-08064 Squeegee Weldment (40 In) 1
13 7-79-00101 Strap, Squeegee Clamp 1
14 2-14-00184 Wheel 2
HARDWARE USED:
H51 2-00-00216 Screw, 3/8-16 x 2.000 HHC 2
H52 2-00-00402 Flat Washer, .750 x .390 x .094 4
H54 2-00-02360 Nut, 3/8-16 Hex. 2
H259 2-00-05343 Bolt Carriage , .38-16 x 3.50 SST 2
H261 2-00-05344 Screw - HHM .313 - 18 x 1.75 STL 2
H283 2-00-03842 Roll Pin, 1/4 x 1.00 2
C1915/0007
