2-44 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
FRONT COVER AND LATCH ASSEMBLY - PARTS LIST
Key No. Part Number Description Qty.
1 7-09-01057 Bushing - Brush Lift 2
2 7-16-07400-1 Cover - Hopper/Battery 1
3 7-18-08003 Detent - Cover Pivot 2
4 7-31-06078 Handle - Cover Latch 1
5 7-41-00044 Latch - Hood 1
6 2-00-03635 Pin - Roll 1
7 7-57-05060 Pivot - Cover (LH) 1
8 7-57-05059 Pivot - Cover (RH) 1
9 7-58-05293 Plate - Light Plate 2
10 7-75-01205 Spacer - Latch 2
11 7-76-00120 Spring - Compression 2
HARDWARE USED:
H10 2-00-00519 Lockwasher, #10 Med HS 2
H26 2-00-00641 Nut, 1/4-20 Insert Fiber 4
H34 2-00-00208 Screw, 5/16-18 x .750 HHC 8
H43 2-00-00409 Flat Washer, .687 x .344 x .062 10
H44 2-00-00530 Lock Washer, 5/16 HS Med. 8
H46 2-00-00644 Nut, 5/16-18, Insert Fiber 4
H54 2-00-02360 Nut, 3/8-16 Hex. 4
H268 2-00-00051 Screw - RH, .25-20 x .75 4
H342 2-00-05444 #10-24 BHCS 1.00 Black Oxide 2
H343 2-00-03994 Carriage Bolt .31-18 x 1.50 4
C1954/0012
