2-76 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
INSTRUMENT PANEL (12V) - PARTS LIST
Key No. Part Number Description Qty.
1 7-52-00171 Panel - Instrument 1
2 7-48-05029 Meter - Hour 1
3 7-82-00041 Switch - Double Pole, Triple Throw (ON-ON-ON) 2
4 7-82-00042 Switch - Motor reversing 1
5 2-00-05375 Blank - McGill Switch 5
6 8-82-00041 Key Switch (Ignition) 1
7 7-10-00035 Control - Solution 1
8 7-10-00034 Cable - Solution Control Ref
9 7-32-09003 Alarm - Chime 1
10 8-82-00030 Switch - Push Button Lid 1
11 7-18-00271 Decal - Instrument Panel (12V) 1
12 8-48-05032 Gauge - Fuel 1
13 7-40-05042 Light - (14V) Amber 2
14 7-40-05028 Light - (14V) Red 3
15 2-00-05418 Blank - Light (Black) 1
15 0795-133 Harness - Instrument Panel 1
16 0775-227 Diode Assembly 1
HARDWARE USED:
H176 2-00-05337 Screw, #8-32 x .750 BHS SS 8
C1925/0004
