3-12 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
STROBE LIGHT W/ OHG (12 & 36 VDC) - PARTS LIST
Key No. Part Number Description Qty.
1 8-58-05228 Plate - Flasher Mounting 1
2 3-61-02014 Convoluted Tube (6 ft.) 1
3 2-00-04578 Terminal (.156 Male Bullet) 2
4 8-40-05020 Red Strobe Light (12 to 80 VDC) 1
4 8-40-05036 Amber Strobe Light (12 to 80 VDC) 1
5 2-00-04345 Ty - Rap 4
*6 3-61-00193 Wire 16 GA (Red) 10 ft.
*7 3-61-00189 Wire 16 GA (Black) 10 ft.
8 2-00-04626 Terminal (.156 Female Bullet) 2
9 2-00-04479 Terminal (3-way) 1
10 2-00-04281 Terminal (#10 Ring) (Only used on IC Engines) 1
*Cut to Suit
HARDWARE USED:
H11 2-00-00605 Nut, Hex MS #10-24 x .375 x .125 2
H15 2-00-00221 Screw, ¼ - 20 x .750 HHC 4
H72 2-00-00518 Lock Washer, Helical Spring 4
H115 2-00-03063 Screw #10-24 x .750 THM 2
H159 2-00-00512 Lock Washer 2
C1946/9906
