2-28 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
SWING SQUEEGEE SUPPORT- PARTS LIST
Key No. Part Number Description Qty.
1 7-03-04211 Arm - Scrub Brush Frame 2
2 7-03-04210 Arm - Squeegee 2
3 7-08-00839 Bracket - Angle 2
4 7-09-01057 Bushing - Brush Lift 8
5 7-89-08073 Caster 1
6 8-15-01002 Collar - Setscrew 6
7 2-00-02216 Hose Clamp 1
8 2-95-04182 Nut - 3/8-16 Elastic Stop Nut 12
9 7-70-05194 Shaft 2
10 7-86-08067 Squeegee Support (Weldment) 1
11 7-81-00232 Support - Squeegee 2
12 7-55-08144 Weldment - Rear Pin Assy 2
13 7-08-00994 Weldment - Bracket Assy L.H. 1
14 7-08-00993 Weldment - Bracket Assy R.H. 1
HARDWARE USED:
H46 2-00-00644 Nut, 5/16-18, Insert Fiber 8
H49 2-00-00209 Screw, 3/8-16 x 1.250 HHC 4
H50 2-00-00234 Screw, 3/8-16 x 1.500 HHC 8
H61 2-00-02616 Screw, 1/2-13 x 3.000 HHC 2
H68 2-00-00640 Nut, Hex Fiber Insert 1/2-20 4
H237 2-00-05356 Screw, 5/16-18 x 1.25 Grade 8 8
C1938/0007
