Page 124
2-74
AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
INSTRUMENT PANEL - PARTS LIST
Key No.
Part Number
Description
Qty.
1
7-52-00171
Panel - Instrument
1
2
7-48-05024
Meter - Battery Condition
1
3
7-40-05041
Light - (32V0 Amber
3
4
7-48-05029
Meter - Hour
1
5
7-82-00041
Switch - Double Pole, Triple Throw (ON-ON-ON)
2
6
7-82-00042
Switch - Motor Reversing
1
7
2-00-05375
Blank - McGill Switch
5
8
8-82-00041
Key Switch (Ignition)
1
9
7-10-00040
Control - Solution
1
10
7-10-00034
Cable - Solution Control
Ref.
11
7-18-00270
Decal - Instrument Panel (36V)
1
12
2-00-05418
Blank - Light (Black)
3
13
7-32-09003
Alarm - Chime
1
14
8-82-00030
Switch - Push Button Lid
1
15
2-00-04757
Plug Button, .375 Dia.
1
16
2-00-05382
Hole Plug
1
17
2-00-04250
Clamp
1
18
7-52-00177
Panel - Broom Lift Switch
1
19
7-18-00279
Decal - Broom Lift Switch
1
20
7-82-00039
Switch - Single Pole, Single Throw (On-On)
1
21
0795-128
Harness - Instrument Panel
1
22
0775-227
Diode Assembly
1
23
0775-234
Resistor Assembly
1
NOTE: Harness 0795-128 Not Shown
HARDWARE USED:
H6
2-00-00056
Screw, #10-24 x .500 RHM
1
H9
2-00-00426
Flatwasher, .500 x .219 x .063
1
H12
2-00-01246
Nut, Hex Fiber Insert #10-24
2
H176
2-00-05337
Screw, #8-32 x .750 BHS SS
8
C1939/0012
