2-40 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
FRONT WHEEL ASSEMBLY - PARTS LIST
Key No. Part Number Description Qty.
1 2-00-03797 Axle Spacer Washer 2
2 7-03-09014 Axle - Front Wheels 1
3 7-08-02007 Brake Disc 2
4 2-00-04621 BRG - Outer Race (Cup Only) 4
5 2-00-00776 Cotter Pin (1/8 DIA. x 1-1/2 LG) 2
6 7-89-08044 Front Wheel (Molded) 16 in. dia. 4
7 8-11-00030 Dust Cap 2
8 7-33-09027 Hub - Front Wheel 2
9 8-23-03056 Nut - Special 2
10 8-23-03065 Nut - Wheel 10
11 2-00-02079 Roller Bearing 4
12 8-79-00030 Static Strap 1
13 8-80-05036 Stud 10
14 8-75-01136 Washer - Thrust 2
HARDWARE USED:
H16 2-00-03051 Screw, ¼-20 x .750 HSHC 10
H46 2-00-00644 Nut, 5/16-18, Insert Fiber 2
H84 2-00-00228 Screw, 5/16-18 x 2.250 HHC 2
H120 2-00-03829 Lock Washer, 3/8 Bolt 2
H149 2-00-01803 Washer, 1.063 x .031 x .063 3
C1902/0008
