Esp recovery option - exploded view – Nilfisk-ALTO 2000 User Manual
Page 135
AMERICAN-LINCOLN TECHNOLOGY
3-5
SMART 2000
ESP RECOVERY OPTION - EXPLODED VIEW
14
15
2
H8
RED
BLACK
4
1
H9
H12
11
NOTE: BLUE SEALANT ON ALL FITTINGS
10
9
8
6
7
EXISTING
HARNESS
H20
12
H26
H247
H248
H332
13
EXISTING
HARNESS
BACK VIEW OF 8-82-00059
EXISTING
HARNESS
REMOVE WIRES 23 AND 28B FROM
HIGH REC SW AND PLUG INTO
ESP FLOAT SE AS SHOWN
5
3
5 24
24
23
28B
5.00
Ø1.06
2.50
9.00
DRILL Ø1.13 IN RECOVERY TANK
AND PLUG ANOTHER HOLE
1.25
7.58
TAPPED FOR 3/8 PIPE
C1944/0008
