Hydraulic kit-0760-546 – Nilfisk-ALTO 2000 User Manual
Page 151
AMERICAN-LINCOLN TECHNOLOGY
3-21
SMART 2000
HYDRAULIC KIT-0760-546
Key No.
Part Number
Description
Qty.
1
7-60-05036
Pump - Hyd.
1
2
0885-094
Hydraulic Motor
1
3
0885-078
Hydraulic Motor - Broom Drive
1
4
7-88-00080
Valve - Steering Control
1
5
7-88-00081
Valve - Solenoid (36V)
1
6
7-24-04013
Filter Assembly, Return
1
7
2-00-04957
Fitting - Cap 8ORS
1
8
2-00-04918
Fitting - Straight Connector
2
9
2-00-05442
Fitting - ORFS M to ORS M Boss 06 x 06
1
10
2-00-04977
Fitting - 9ORS - 6SAE, Str.
6
11
2-00-04974
Fitting - #8 ORS to # 10 SAE Connector
2
12
2-00-05441
Fitting - Long Str Male ORFS to ORS Boss 6x6
1
13
2-00-04895
Fitting - Straight Connector
2
14
2-00-05438
Fitting - 90 ORFS M to NPTF < 8 x 12
1
15
2-00-04892
Fitting - 90º Elbow (O-Ring)
4
16
2-00-05435
Fitting - 90 ORFS to ORS Boss 06 x 06
2
17
2-00-05437
Fitting - 90 ORFS to ORS Boss 08 x 06
1
18
2-00-04885
Fitting - 90º Elbow (O-Ring)
1
19
2-00-04924
Fitting - ¾-16 x 13/16-16 Tee
1
20
2-00-05440
Fitting - ORFA Female Swivel to ORS Boss M 06
1
21
2-00-05436
Fitting - ORFS M to NPTF M 08 x 12
1
22
7-33-02417
Hose - #8 Str-45, 13/16-16 Both Ends, 27.0 Lg
1
23
8-33-02179
Hose - #4 Str-Str, 9/16-18 Both Ends, 46.0 Lg
1
24
8-33-02184
Hose - #4 Str-Str, 9/16-18 Both Ends, 50.5
1
25
7-33-02428
Hose - #8 Str-90, 13/16-16 Both Ends, 57.0 Lg
1
26
2-00-04921
Fitting - IOSAE 90°-8ORS
3
27
8-33-02325
Hose - #8 Str-Str, 13/16-16 Both Ends, 65.0 Lg
1
28
7-33-02412
Hose - #8 Str-90, 13/16-16 Both Ends, 56.0 Lg
1
29
2-00-04928
Fitting - 13/16 - 16 x13/16 - 16 Tee
1
30
7-33-02414
Hose - #8 Str-Str, 13/16-16 Both Ends, 82.0 Lg
1
31
7-33-02416
Hose - #6 Str-Str, 11/16-16 - 13/16-16, 58.0 Lg
1
32
2-00-04916
Plug - 9/16-16 O-Ring Boss
1
33
7-33-02431
Hose - #6 Str-Str, 13/16-16 Both Ends, 82.0 Lg
1
34
2-00-04973
Fitting - 12ORFS 12ORB, Str
1
35
2-00-04975
Fitting - 8SAE 45º Elbow
1
36
2-00-05439
Fitting - ORFS M To NPFT m 08 X 08
1
37
2-00-05453
Fitting - 12ORFS - ½NPT, Str.
1
38
2-00-05458
Fitting - Reducer 10 ORB M To 12 ORB F
1
39
2-00-05477
Fitting - Reducer, 8ORFS to 6ORFS
1
40
2-00-05481
Fitting - ORS To ORS Boss 06 x 06 Tee
1
41
7-33-02191
Hose - #4 Str -90, 9/16 - 18 Both Ends, 42 Lg
1
42
7-33-02222
Hose - #8 Str-Str, 13/16-16 Both Ends, 26.0 Lg
1
43
7-33-02225
Hose - #4 Str-90, 9/16 - 18 Both Ends, 38 LG
1
44
7-33-02402
Hose - #9 Str-90, 13/16-16 Both Ends, 22.0 Lg
1
45
7-33-02438
Hose - #8 Str-Str, 13/16-16 Both Ends, 51 Lg
1
46
7-33-02439
Hose - #6 90-45, 11/16-16 Both Ends, 20 Lg
1
47
7-33-02446
Hose-#12 Str-90, 1 3/16-12 Both End, 22.5±.25 Lg
1
