3-10 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
STROBE LIGHT W/O OHG (12 & 36 VDC) - PARTS LIST
Key No. Part Number Description Qty.
1 7-81-00223 Support - Warning Light 1
2 3-61-02014 Convoluted Tube (6 ft.) 1
3 2-00-03261 Grommet 1
4 2-00-00491 Grommet 1
5 8-40-05020 Red Strobe Light (12 to 80 VDC) 1
5 8-40-05036 Amber Strobe Light (12 to 80 VDC) 1
*6 3-61-00193 Wire - 16 GA (Red) 10 ft.
*7 3-61-00189 Wire - 16 GA (Black) 10 ft.
8 2-00-04578 Terminal (.156 Male Bullet) 2
9 2-00-04626 Terminal (.156 Female Bullet) 2
10 2-00-04479 Terminal (3-way) 1
11 2-00-04281 Terminal (#10 Ring) (Only used on IC Engines) 1
*Cut to Suit
HARDWARE USED:
H11 2-00-00605 Nut, Hex MS #10-24 x .375 x .125 2
H48 2-00-00233 Screw, 3/8-16 x 1.000 HHC 4
H52 2-00-00402 Flat Washer, .750 x .390 x .094 8
H53 2-00-02310 Lock Washer, Helical Spring 3/8 Med. 4
H54 2-00-02360 Nut, 3/8-16 Hex. 4
H115 2-00-03063 Screw, #10-24 x .750 THM 2
H159 2-00-00512 Lock Washer 2
C1945/9906
