Electrical power panel (36v) - parts list – Nilfisk-ALTO 2000 User Manual
Page 122
2-72
AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
ELECTRICAL POWER PANEL (36V) - PARTS LIST
Key No.
Part Number
Description
Qty.
1
7-52-00176
Panel - Power
1
2
0775-225
Wire Assembly - Battery to Power Panel
1
3
8-06-05004
Terminal Block
3
4
7-74-00007
Contactor
2
5
2-00-04825
Solenoid
1
6
7-64-00023
36V/VDC Shutdown N.C.
1
7
8-64-00008
Circuit Breaker (15 AMP)
7
8
8-11-00044
Boot
7
9
7-64-00032
Circuit Breaker (50 AMP)
1
10
8-11-00051
Cap - Clear Boot
4
11
7-64-00020
Circuit Breaker (45 AMP)
2
12
8-28-05021
Fuse (120 AMP)
1
13
8-74-00014
Solenoid, Power Panel
1
14
0775-238
Controller - Motor
1
15
7-64-00037
Relay - 36v w/ Diode Assembly
9
16
7-64-00038
Relay - Time Delay (3 sec on Load)
1
17
7-64-00025
Circuit Breaker - 25 Amp
1
18
7-16-07421
Cover - Power Panel
1
19
7-35-00023
Insulation - Power Panel Cover
1
HARDWARE USED:
H6
2-00-00049
Screw, #10-24 x .500 RHM
10
H8
2-00-00039
Screw, 10-24 x 1.000 RHM
3
H9
2-00-00426
Flat Washer, .500 x .219 x .063
12
H12
2-00-01246
Nut, Hex Fiber Insert #10-24
22
H20
2-00-00203
Screw, ¼-20 x 1.500 HHC
2
H25
2-00-00594
Nut, Hex ¼ - 20 x .437 x .218
6
H27
2-00-03702
Washer, .625 x .281 x .063
6
H34
2-00-00208
Screw, 5/16-18 x .750 HHC
2
H43
2-00-00409
Flat Washer, .687 x .344 x .062
4
H46
2-00-00644
Nut 5/16-18, Insert Fiber
4
H72
2-00-00518
Lock Washer, Helical Spring
3
H136
2-00-03940
Screw, #10-24 x .500 T/C HH
2
H187
2-00-00071
Screw, #10-24 x 1.2500 RHM
3
H363
2-00-02336
Screw, HHC, .375-16 x 2.75
2
