2-60 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
HYDRAULIC FILTER AND SOLENOID ASSEMBLY - PARTS LIST
Key No. Part Number Description Qty.
*1 7-60-05036 Pumo - Hyd Ref.
2 7-08-00980 Brkt - Filter Mtg 1
*3 7-24-04013 Filter Assembly, Return Ref.
4 7-08-00984 Brkt - Valve Mtg 1
*5 7-88-00081 Valve - Solenoid (36V) Ref.
*6 2-00-04916 Plug - 9/16-16 O-Ring Boss Ref.
*7 2-00-05452 Fitting - 12ORFS - 100RB, Str. Ref.
*8 2-00-04921 Fitting - 10SAE 90º - 8ORS Ref.
*9 2-00-04977 Fitting - 8ORS - 6SAE Str. Ref.
*10 2-00-05441 Fitting, Long Str Male ORFS to ORS Boss 06x06 Ref.
*11 2-00-05440 Fitting - ORFS Female Swivel to ORS Boss M 06 Ref.
*12 2-00-04975 Fitting - 8SAE 45º Elbow Ref.
*13 2-00-04924 Fitting - 3/4-16 x 13/16-16 Tee Ref.
*14 2-00-04957 Fitting - Cap 8ORS Ref.
*15 2-00-05437 Fitting - 90 ORS to ORS Boss 08 x 06 Ref.
*16 2-00-05438 Fitting - 90 ORS M to NOTF M 08 x 12 Ref.
*17 2-00-04928 Fitting - 13/16-16 x 13/16-16 Tee Ref.
*18 2-00-04885 Fitting - 90º Elbow (O-Ring) Ref.
*19 2-00-05436 Fitting - ORFS M to NPTF M 08 x 12 Ref.
20 7-88-00085 Valve - Broom Actuator 1
*21 2-00-05480 Fitting - Long 90º Elbow (O-Ring) Ref.
*22 2-00-04892 Fitting - 90º Elbow (O-Ring) Ref.
*23 2-00-05435 Fitting - 90 Orfs to Ors Boss 06 x 06 Ref.
*24 2-00-05481 Fitting - Orfs to Ors Boss 06 x 06, Tee Ref.
*25 2-00-05477 Fitting - Reducer, 8Orfs to 6Orfs Ref.
26 7-87-02204 Tube - Broom Manifold 1
* ITEMS ARE PART OF HYDRAULIC KIT 0760-546
HARDWARE USED:
H15 2-00-00221 Screw, 1/4-20 x .750 HHC 4
H21 2-00-01769 Screw, 1/4-20 x 1.750 HHC 2
H26 2-00-00641 Nut, 1/4-20 Insert Fiber 2
H27 2-00-03702 Washer, .625 x .281 x .063 6
H46 2-00-00644 Nut, 5/16-18, Insert Fiber 2
H72 2-00-00518 Lock Washer, Helical Spring 4
C1965/0101
