2-32 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
SOLUTION CONTROL- PARTS LIST
Key No. Part Number Description Qty.
1 7-88-00073 Valve - Solution (36VDC) 2
2 2-95-04182 Nut - 3/8-16 Elastic Stop Nut 1
3 2-00-04564 Clamp - Cable 1
4 7-08-00991 Brkt-Elbow 1
5 7-88-00079 Valve 1
6 7-41-05116 Lever-valve 1
7 7-57-05018 Wire Swivel 1
8 2-00-02000 Roll Pin 1
9 7-25-02053 90º Elbow (¾ NPT to ¾ Barb)
10 7-25-02012 Fitting - 3/4 I.D. Hose Str. Barb 1
11 2-00-04250 Clamp 1
12 7-10-00034 Cable-Solution control 1
13 2-00-05253 Clamp 1
14 7-25-02012 Fitting - 3/4 I.D. Hose Str. Barb 1
HARDWARE USED:
H7 2-00-00056 Screw, #10-24 x .750 RHM 1
H12 2-00-01246 Nut, Hex Fiber Insert #10-24 1
H17 2-00-00205 Screw, ¼-20 x 1.000 HHC 2
H25 2-00-00594 Nut, Hex ¼-20 x.437x.218 1
H26 2-00-00641 Nut, ¼-20 Insert Fiber 3
H27 2-00-03702 Washer, .625x.218x.063 2
H189 2-00-00460 Flatwasher, .437 x .192 x .031-s 1
H345 2-00-00249 Screw - HHM 8-32 x .375 Brass/Chr 1
C1917/0012
