3-18 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
SPRAY & VAC WAND (12V & 36V) (cont.) - PARTS LIST
Key No. Part Number Description Qty.
1 7-08-00769 Bracket - Hose Connection 1
2 2-00-05465 Adapter, 1/4 Female x 1/8 Male 1
3 2-00-05464 Elbow 1/4 NPT x Barb Fitting 3/8 1
4 7-16-05028 Coupling - Quick Disconnect 1
5 2-00-05363 Hose Clamp 4
6 7-60-05017 Pump - Water 36VDC
6 7-60-05022 Pump - Water 12 VDC (Used on IC Engine) 1
7 2-00-05201 Fitting - Str. 1/2 NPT x 3/8 Barb 2
8 7-25-02012 Fitting - 3/4 I.D. Hose Str Barb 1
9 7-25-02037 Fitting - Plastic (Tee) 1
10 2-00-04655 Fitting - 90º Elbow (Nylon) 1
11 7-25-02053 90º Elbow (¾ NPT to ¾ BARB) 1
12 2-00-03407 Hose Clamp - Witteck #10P 3
13 8-82-00059 Switch - Rocker (SPST) 1
14 7-18-00278 Decal - Vac Wand 1
15 3-71-00081 Hose, Pump to Spray 35.50”
16 3-71-03025 Hose, Tank to Tee 2.75”
17 3-71-00081 Hose, Pump to Spray 30.00”
HARDWARE USED:
H12 2-00-01246 Nut, Hex Fiber Insert #10-24 4
H15 2-00-00221 Screw, 1/4-20 x .750 HHC 1
H25 2-00-00594 Nut, Hex 1/4-20 x .437 x .218 1
H72 2-00-00518 Lockwasher, Helical Spring 1
H116 2-00-01951 Carriage Bolt, 1/4-20 x 1.250 4
H189 2-00-00460 Flatwasher, .437 x .192 x .031 - s 4
H281 2-00-00415 Flatwasher, .9375 x .468 x .0625 Stl 2
C1952/0102
