30 AT-WR4500 Series - IEEE 802.11abgh Outdoor Wireless Routers
RouterOS v3 Configuration and User Guide
4 Configuring Interfaces
4.1 General Interface Settings
Document revision: 1.1 (Fri Mar 0 5 08:08:52 GMT 200 4)
Applies to: V2.9
4.1.1
General Information
Summary
AT-WR4500 RouterOS supports a variety of physical and virtual interfaces (like Bonding, Bridge, VLAN
etc.). Each of them has its own submenu, but there is also a list of all interfaces where some common
properties can be configured.
Description
The Manual describes general settings of RouterOS interfaces.
4.1.2
Interface Status
Submenu level: /interface
Property Description
mtu (integer) - maximum transmission unit for the interface (in bytes)
name (text) - the name of the interface
type (read-only: arlan | bonding | bridge | cyclades | eoip | ethernet | farsync | ipip | isdn-client |
isdn-server | l2tp-client | l2tp-server | moxa-c101 | moxa-c502 | mtsync | pc | ppp-client | ppp-server |
pppoe-client | pppoe-server | pptp-client | pptp-server | pvc | radiolan | sbe | vlan | wavelan | wireless| xpeed) -
interface type
Example
To see the list of all available interfaces:
[admin@AT-WR4562] interface> print
Flags: X - disabled, D - dynamic, R - running
# NAME TYPE RX-RATE TX-RATE MTU
0 R ether1 ether 0 0 1500
1 R bridge1 bridge 0 0 1500
2 R ether2 ether 0 0 1500
3 R wlan1 wlan 0 0 1500
[admin@AT-WR4562] interface>
4.1.3
Traffic Monitoring
Command name: /interface monitor-traffic
Description
The traffic passing through any interface can be monitored.
Property Description
received-bits-per-second (read-only: integer) - number of bits that interface has received in one
second
received-packets-per-second (read-only: integer) - number of packets that interface has received
in one second
sent-bits-per-second (read-only: integer) - number of bits that interface has sent in one second
sent-packets-per-second (read-only: integer) - number of packets that interface has sent in one second
