Add the same area as in previous routers:
[admin@OSPF_peer_2] routing ospf area> print
Flags: X - disabled, I - invalid
# NAME AREA-ID STUB DEFAULT-COST
AUTHENTICATION
0 backbone 0.0.0.0
none
1 local_10 0.0.0.1 no 1
none
Add connected networks with the same area:
[admin@OSPF_peer_2] routing ospf network> print
Flags: X - disabled, I - invalid
# NETWORK AREA
0 10.2.0.0/24 local_10
1 10.3.0.0/24 local_10
After all routers have been set up as described above, and the links between them are operational, the
routing tables of the three routers look as follows:
[admin@OSPF_MAIN] ip route> print
Flags: X - disabled, I - invalid, D - dynamic, J - rejected,
C - connect, S - static, r - rip, o - ospf, b - bgp
# DST-ADDRESS G GATEWAY DISTANCE INTERFACE
0 Io 192.168.0.0/24
110
1 DC 192.168.0.0/24 r 0.0.0.0 0 main_gw
2 Do 10.3.0.0/24 r 10.2.0.1 110 to_peer_2
r 10.1.0.1 to_peer_1
3 Io 10.2.0.0/24
110
4 DC 10.2.0.0/24 r 0.0.0.0 0 to_peer_2
5 Io 10.1.0.0/24
110
6 DC 10.1.0.0/24 r 0.0.0.0 0 to_peer_1
[admin@OSPF_peer_1] ip route> print
Flags: X - disabled, I - invalid, D - dynamic, J - rejected,
C - connect, S - static, r - rip, o - ospf, b - bgp
# DST-ADDRESS G GATEWAY DISTANCE INTERFACE
0 Do 192.168.0.0/24 r 10.1.0.2 110 to_main
1 Io 10.3.0.0/24
110
2 DC 10.3.0.0/24 r 0.0.0.0 0 backup
3 Do 10.2.0.0/24 r 10.1.0.2 110 to_main
r 10.3.0.2 backup
4 Io 10.1.0.0/24
110
5 DC 10.1.0.0/24 r 0.0.0.0 0 to_main
[admin@OSPF_peer_2] ip route> print
Flags: X - disabled, I - invalid, D - dynamic, J - rejected,
C - connect, S - static, r - rip, o - ospf, b - bgp
# DST-ADDRESS G GATEWAY DISTANCE INTERFACE
0 Do 192.168.0.0/24 r 10.2.0.2 110 to_main
1 Io 10.3.0.0/24
110
2 DC 10.3.0.0/24 r 0.0.0.0 0 to_peer_1
3 Io 10.2.0.0/24
110
4 DC 10.2.0.0/24 r 0.0.0.0 0 to_main
5 Do 10.1.0.0/24 r 10.3.0.1 110 to_peer_1
r 10.2.0.2 to_main
