AT-WR4500 Series - IEEE 802.11abgh Outdoor Wireless Routers
RouterOS v3 Configuration and User Guide
Bonding configuration
for Office1
[admin@office1] interface bonding> add slaves=eoip-tunnel1,eoip-tunnel2
[admin@office1] interface bonding> print
Flags: X - disabled, R - running
0 R name="bonding1" mtu=1500 mac-address=00:0C:42:03:20:E7 arp=enabled
slaves=eoip-tunnel1,eoip-tunnel2 mode=balance-rr primary=none
link-monitoring=none arp-interval=00:00:00.100 arp-ip-targets=""
mii-interval=00:00:00.100 down-delay=00:00:00 up-delay=00:00:00
lacp-rate=30secs
[admin@office1] ip address> add address=3.3.3.1/24 interface=bonding1
[admin@office1] ip address> print
Flags: X - disabled, I - invalid, D - dynamic
# ADDRESS NETWORK BROADCAST INTERFACE
0 1.1.1.1/24 1.1.1.0 1.1.1.255 isp2
1 10.1.0.111/24 10.1.0.0 10.1.0.255 isp1
2 3.3.3.1/24 3.3.3.0 3.3.3.255 bonding1
for Office2
[admin@office2] interface bonding> add slaves=eoip-tunnel1,eoip-tunnel2
[admin@office2] interface bonding> print
Flags: X - disabled, R - running
0 R name="bonding1" mtu=1500 mac-address=00:0C:42:03:20:E7 arp=enabled
slaves=eoip-tunnel1,eoip-tunnel2 mode=balance-rr primary=none
link-monitoring=none arp-interval=00:00:00.100 arp-ip-targets=""
mii-interval=00:00:00.100 down-delay=00:00:00 up-delay=00:00:00
lacp-rate=30secs
[admin@office2] ip address> add address=3.3.3.2/24 interface=bonding1
[admin@office2] ip address> print
Flags: X - disabled, I - invalid, D - dynamic
# ADDRESS NETWORK BROADCAST INTERFACE
0 2.2.2.1/24 2.2.2.0 2.2.2.255 isp2
1 10.1.0.112/24 10.1.0.0 10.1.0.255 isp1
2 3.3.3.2/24 3.3.3.0 3.3.3.255 bonding1
[admin@office2] ip address> /ping 3.3.3.1
3.3.3.1 64 byte ping: ttl=64 time=2 ms
3.3.3.1 64 byte ping: ttl=64 time=2 ms
2 packets transmitted, 2 packets received, 0% packet loss
round-trip min/avg/max = 2/2.0/2 ms
8.4 IPIP Tunnel Interfaces
Document revision:
1.1 (Fri Mar 0 5 08:25:43 GMT 200 4)
Applies to:
V2.9
8.4.1
General Information
Summary
The IPIP tunneling implementation on the RouterOS is RFC 2003 compliant. IPIP tunnel is a simple
protocol that encapsulates IP packets in IP to make a tunnel between two routers. The IPIP tunnel
interface appears as an interface under the interface list. This protocol makes multiple network schemes
possible.
IP tunneling protocol adds the following possibilities to network setup:
•
to tunnel Intranets over the Internet
•
to use it instead of source routing
Quick Setup Guide
To make an IPIP tunnel between two RouterOS routers with IP addresses 10.5.8.104 and 10.1.0.172,
using IPIP tunnel addresses 10.0.0.1 and 10.0.0.2, follow the next steps.
Configuration on router with IP address 10.5.8.104:
