Page 42

Command Reference
42
Beijer Electronics, MAEN993
5.6.16 LAU_CONFIG_SETCOMSERMODE
(0x0110)
SCOM Serial Interface Mode
The serial interface mode indicates the physical type of the serial interface used for
the SCOM communication. Available modes are RS232 and RS485. RS232 allows
a point-to-point communication, i.e. computer and Beijer Electronics RBC or Beijer
Electronics RBC and Beijer Electronics RBC. With RS485, many devices can be at-
tached to the same physical line and can be controlled by one or more computers,
allowing a kind of networking. Limitation is given only by the physical characteristics
of the RS485 bus.
This command sets the software configured serial interface mode. It is used, if the
device is configured to override the DIL switch settings.
Supported since Firmware Version
LAUER RBC: 0.0.0.1
Command Stream
Response Message (Acknowledge)
Note:
The changes made by this command will become active only after a restart of the de-
vice. This avoids loosing the connection to the device during configuration.
0
1
2
3
4
5
6
7...9
10
0x07
ADR
0x4C
0x41
0x55
0x03
ICHKH 0x01
0x10
Param ICHKD
Param
Value:
0x00: The serial interface will be configured as RS232
0x01: The serial interface will be configured as RS485
Type:
Byte
Length:
1
Description: Software configured serial interface mode used for SCOM
communication
0
1
2
3
4
5
6
7
8
0x06
ADR
0x4C
0x41
0x55
0x01
ICHKH
Ret
ICHKD
Ret
Value:
0x00: The serial interface is configured as RS232
0x01: The serial interface is configured as RS485
Type:
Byte
Length:
1
Description: Indicates which interface is used if the software settings are
used
