Command Reference
Beijer Electronics, MAEN993 29
5.6.7 LAU_CONFIG_GETPOTMODE (0x0113)
POT Mode
Returns the local backlight level control configuration. If the local backlight control
is enabled, the backlight level can be changed using the front panel buttons and by
remote control (via RS232, RS485 or USB interface). If the local backlight control
is disabled, the backlight level cannot be changed using the front panel buttons. It
can be still changed by any remote control option. The configured backlight level
control can be temporarily overridden by the SCOM command “POT”.
Supported since Firmware Version
LAUER RBC: 0.0.0.1
Command Stream
Response Message (Acknowledge)
Response Message (Negative Acknowledge)
Under normal operation conditions, a device never sends a negative acknowledge in
response to this command.
Maximum Lr for this Command
9
Example
Get the local backlight level control configuration of the device at address 0.7 (group
0, address 7):
According to the data returned by the device at address 0.7 (group 0, address 7), the
local backlight level control is enabled:
0 1 2 3 4 5 6 7...8 9
0x07 ADR 0x4C 0x41 0x55 0x02 ICHKH 0x01 0x13 ICHKD
0 1 2 3 4 5 6 7 8
0x06 ADR 0x4C 0x41 0x55 0x01 ICHKH Ret ICHKD
Ret
Value: 0x00: Local backlight level control enabled
0x01: Local backlight level control disabled
Type: Byte
Length: 1
Description: Local backlight level control mode
0 1 2 3 4 5 6 7...8 9
0x07 0x07 0x4C 0x41 0x55 0x02 0x0D 0x01 0x13 0xEB
0 1 2 3 4 5 6 7 8
0x06 0x07 0x4C 0x41 0x55 0x01 0x0F 0x00 0xFF
