5.6.8 LAU_CONFIG_GETREMOTECONTROL

(0x011C)

Remote Control Configuration

This command returns the configuration value that indicates whether the device is
configured to act as a remote controller. Beijer Electronics RBCs can be used as pas-
sive devices, but can also be set up as remote controller devices to alter the backlight
level of any other device within the network every time the backlight is changed by
the buttons at the front of the device.

Supported since Firmware Version
LAUER RBC: 0.0.0.1

Command Stream

Response Message (Acknowledge)

Response Message (Negative Acknowledge)
Under normal operation conditions, a device never sends a negative acknowledge in
response to this command.

Maximum Lr for this Command
9

Example
Check if the device at address 0.7 (group 0, address 7) is configured to control other
devices remotely within a network:

According to the data returned by the device at address 0.7 (group 0, address 7), the
device is capable to control other devices remotely within a network:

0

1

2

3

4

5

6

7...8

9

0x07

ADR

0x4C

0x41

0x55

0x02

ICHKH 0x01

0x1C

ICHKD

0

1

2

3

4

5

6

7

8

0x06

ADR

0x4C

0x41

0x55

0x01

ICHKH

Ret

ICHKD

Ret

Value:

0x00: Remote control capability is disabled
0x01: Remote control capability is enabled

Type:

Byte

Length:

1

Description: Indicates whether the device is used also as remote controller

0

1

2

3

4

5

6

7...8

9

0x07

0x07

0x4C

0x41

0x55

0x02

0x0D

0x01

0x1C

0xE2

0

1

2

3

4

5

6

7

8

0x06

0x07

0x4C

0x41

0x55

0x01

0x0F

0x01

0xFE
