Command Reference

Beijer Electronics, MAEN993

27

5.6.5 LAU_CONFIG_GETDISPLAYADR (0x010F)

Device Address

Returns the software configured device address. This address is used, if the device is
configured to override the DIL (DIP) switch settings. The returned address does not
contain group information.

Supported since Firmware Version
LAUER RBC: 0.0.0.1

Command Stream

Response Message (Acknowledge)

Response Message (Negative Acknowledge)
Under normal operation conditions, a device never sends a negative acknowledge in
response to this command.

Maximum Lr for this Command
9

Example
Read the software configured device address (excluding group) from the device at ad-
dress 14.7 (group 14, address 7):

According to the data returned by the device at address 14.7 (group 14, address 7),
the devices software configured address without group is 0x07:

0

1

2

3

4

5

6

7...8

9

0x07

ADR

0x4C

0x41

0x55

0x02

ICHKH 0x01

0x0F

ICHKD

0

1

2

3

4

5

6

7

8

0x06

ADR

0x4C

0x41

0x55

0x01

ICHKH

Ret

ICHKD

Ret

Value:

0...15 (0x00...0x0F)

Type:

Byte

Length:

1

Description: Software configured device address

0

1

2

3

4

5

6

7...8

9

0x07

0xE7

0x4C

0x41

0x55

0x02

0x2D

0x01

0x0F

0xEF

0

1

2

3

4

5

6

7

8

0x06

0xE7

0x4C

0x41

0x55

0x01

0x2F

0x07

0xF8
