Page 38

Command Reference

Beijer Electronics, MAEN993

5.6.14 LAU_CONFIG_SETDILMODE (0x018E)

DIL Switch Mode

For a base configuration, Beijer Electronics RBCs are equipped with DIL (DIP)
switches, where the device address and the serial interface mode can be selected. Be-
sides this configuration option, Beijer Electronics RBCs allow full software configu-
ration, which is stored in an internal Flash memory. The software configuration also
includes device address and serial interface mode setting. The value set by this com-
mand decides if the device uses hardware settings selected with the DIL switches, or
if it uses software settings stored in internal memory.

Supported since Firmware Version
LAUER RBC: 0.0.0.1

Command Stream

Response Message (Acknowledge)

Response Message (Negative Acknowledge)
Under normal operation conditions, a device never sends a negative acknowledge in
response to this command.

Maximum Lr for this Command
9

Note:

The changes made by this command will become active only after a restart of the de-

vice. This avoids loosing the connection to the device during configuration.

7...9

0x07

ADR

0x4C

0x41

0x55

0x03

ICHKH 0x01

0x8E

Param

ICHKD

Param

Value:

0x00: Configure the device to use the DIL switch settings
0x01: Configure the device to use the software settings

Type:

Byte

Length:

Description: Use the DIL switch settings or the software settings

0x06

ADR

0x4C

0x41

0x55

0x01

ICHKH

Ret
