Command Reference

18

Beijer Electronics, MAEN993

5.4 POT

Local Control

Enables or disables the local backlight level control. If the local backlight control is
enabled, the backlight level can be changed using the front panel buttons and by re-
mote control (RS232, RS485 or USB interface). If the local backlight control is dis-
abled, the backlight level cannot be changed using the front panel buttons. It can still
be changed by any remote control message.

Supported since Firmware Version
LAUER RBC: 0.0.0.1

Command Stream

Response Message (Acknowledge)

Response Message (Negative Acknowledge)

0

1

2

3

4

5

6

7

8

0x07

ADR

0x50

0x4F

0x54

0x01

ICHKH Local control

ICHKD

Local control

Value:

0x00: Disable local backlight control
0xFF: Enable local backlight control

Type:

Byte

Length:

1

Description: New local control configuration

0

1

2

3

4

5

6

7

8

0x06

ADR

0x50

0x4F

0x54

0x01

ICHKH Local control

ICHKD

Local control

Value:

0x00: Local backlight control disabled
0xFF: Local backlight control enabled

Type:

Byte

Length:

1

Description: Current local control configuration

0

1

2

3

4

5

6

7

8

0x15

ADR

0x50

0x4F

0x54

0x01

ICHKH Local control

ICHKD

Local control

Value:

0x00: Local backlight control disabled
0xFF: Local backlight control enabled

Type:

Byte

Length:

1

Description: Last local backlight control configuration
