5.6.4 LAU_CONFIG_GETDILMODE (0x010E)
DIL Switch Mode
For a base configuration, Beijer Electronics RBCs are equipped with DIL (DIP)
switches, where the device address and the serial interface mode can be selected. Be-
sides this configuration option, Beijer Electronics RBCs allow full software configu-
ration, which is stored in an internal flash memory. The software configuration also
includes device address and serial interface mode setting. The value returned with
this command indicates whether the device uses hardware settings selected with the
DIL switches, or software settings stored in the internal memory.
Supported since Firmware Version
LAUER RBC: 0.0.0.1
Command Stream
Response Message (Acknowledge)
Response Message (Negative Acknowledge)
Under normal operation conditions, a device never sends a negative acknowledge in
response to this command.
Maximum Lr for this Command
9
Example
Check, whether the device at address 0.7 (group 0, address 7) overrides the DIL set-
tings (i.e. device address and serial interface mode):
According to the data returned by the device at address 0.7 (group 0, address 7), the
device uses DIL settings:
0
1
2
3
4
5
6
7...8
9
0x07
ADR
0x4C
0x41
0x55
0x02
ICHKH 0x01
0x0E
ICHKD
0
1
2
3
4
5
6
7
8
0x06
ADR
0x4C
0x41
0x55
0x01
ICHKH
Ret
ICHKD
Ret
Value:
0x00: Device is configured to use the DIL switch settings
0x01: Device is configured to use the software settings
Type:
Byte
Length:
1
Description: Indicates whether the device should the DIL switch settings
0
1
2
3
4
5
6
7...8
9
0x07
0x07
0x4C
0x41
0x55
0x02
0x0D
0x01
0x0E
0xF0
0
1
2
3
4
5
6
7
8
0x06
0x07
0x4C
0x41
0x55
0x01
0x0F
0x00
0xFF
