Command Reference
28 Beijer Electronics, MAEN993
5.6.6 LAU_CONFIG_GETCOMSERMODE
(0x0110)
SCOM Serial Interface Mode
The serial interface mode indicates the physical type of the serial interface used for
the SCOM communication. Available modes are RS232 and RS485. RS232 allows
a point-to-point communication, i.e. computer and Beijer Electronics RBC or Beijer
Electronics RBC and Beijer Electronics RBC. With RS485, many devices can be at-
tached to the same physical line and can be controlled by one or more computers,
allowing a kind of networking.
Limitation is given only by the physical characteristics of the RS485 bus.
This command returns the software configured serial interface mode. It is used if the
device is configured to override the DIL switch settings. This mode may differ from
the current mode in use.
Supported since Firmware Version
LAUER RBC: 0.0.0.1
Command Stream
Response Message (Acknowledge)
Response Message (Negative Acknowledge)
Under normal operation conditions, a device never sends a negative acknowledge in
response to this command.
Maximum Lr for this Command
9
Example
Get the serial interface configuration of the device at address 0.7 (group 0, address 7):
According to the data returned by the device at address 10.7 (group 0, address 7), the
serial interface is configured as RS232:
0 1 2 3 4 5 6 7...8 9
0x07 ADR 0x4C 0x41 0x55 0x02 ICHKH 0x01 0x10 ICHKD
0 1 2 3 4 5 6 7 8
0x06 ADR 0x4C 0x41 0x55 0x01 ICHKH Ret ICHKD
Ret
Value: 0x00: The serial interface is configured as RS232
0x01: The serial interface is configured as RS485
Type: Byte
Length: 1
Description: Software configured serial interface mode used for SCOM
communication
0 1 2 3 4 5 6 7...8 9
0x07 0x07 0x4C 0x41 0x55 0x02 0x0D 0x01 0x10 0xEE
0 1 2 3 4 5 6 7 8
0x06 0x07 0x4C 0x41 0x55 0x01 0x0F 0x00 0xFF
