Appendix B
46
Reply to request breakers status command:
Same format as “Request Bus Status”; contains addresses and
status of the breakers specifi ed in the request command
Reply to request all breakers status command: status of
all breakers
0xB0, 0xB6, byte_1, …, byte_84, 0xF0
byte_i: bits 7-4: status of breaker # 2i, bits 3-0: status of breaker
# 2i-1, i=1-84
Reply to request bus status command: status of all
breakers of the requested bus
0xB0, 0xBE, byte_1, …, byte_11, 0xF0
byte_i format is identical to 3.9, except i=1-11
Breaker status description (4 bits)
Value
1
2
3
4
5
Status
Off On
Tripped
Faulty
Empty
Activate zone
0xB0, 0xB7, zone_number_1, …, zone_number_m, 0xF0
zone_number_1, … zone_number_m – numbers of zones to
be activated m<=12
Deactivate zone
0xB0, 0xB8, zone_number_1, …, zone_number_n, 0xF0
zone_number_1, … zone_number_n – numbers of zones to be
deactivated n<=12
Activate/deactivate zone
0xB0, 0xB7, zone_number_1, … zone_number_m, 0xB8, zone_
number_1, …, zone_number_n, 0xF0
zone_number_1, … zone_number_m – numbers of zones to
be activatedzone_number_1, … zone_number_n – numbers of
zones to be deactivatedm+n<=12
Request zones status
0xB0, 0xB9, 0xF0
Zone Related Commands
