16
Installation
Final Check Lists
WaRNING!!
Final check list must be performed by a quali-
fied installer only.
ELECTRICaL CONTROL COMPaRTMENT
• Voltage to appliance matches rating plate
PLUMBING FINaL CHECK
• Incoming water pressure within appliance specifica-
tion.
• Atmospheric vented drain in place.
• Water feed lines intact without leaks.
• Ensure proper clearance as detailed.
• Delime system has been primed. BCX-14 only.
OVEN OPERaTIONaL TESTS
NOTE: Checks to be made by customer or authorized
service agent.
Cool down Mode
• Check that the fan runs with the door open.
Steam Mode - BCX-14 and BX-14 only
Turn on STEAM mode and set thermostat to steam. Verify
the following:
• Heat demand lamp is on.
• Heat demand lamp shuts off at approximately 212ºF
(100ºC).
• Set timer for 1 minute by rotating the knob. Be sure
the buzzer sounds when the time expires.
• Run light (power light) turns on.
• Unit produces steam, window fogs, door seal does
not leak.
Combi Mode - BCX-14 and BX-14 only
Turn to COMBI mode, set thermostat to 350ºF (177ºC)
and verify:
• Heat demand lamp is on.
• Oven is heating.
• Heat demand lamp shuts off at 350ºF (177ºC) and
oven maintains 350ºF (177ºC).
• Fan shuts off with door open.
Hot air Mode - all models
Turn to HOT AIR mode and set thermostat to 400ºF
(204ºC) and verify:
• Heat demand lamp is on.
• Oven is heating.
• Heat demand lamp shuts off at 400ºF (204ºC) and
oven maintains 400ºF (204ºC).
• Fan shuts off with door open.
Steam On demand Mode - BCX-14 and BX-14 only
Turn the oven to Hot Air mode. Set Steam On Demand for
1 minute. Press the Steam On Demand knob and verify:
• Steam demand lamp is on.
• Steam demand lamp shuts off after approximately 1
minute.
Lights
• Press switch to ensure lights come on.
Cavity Vent
• Press switch to ensure that the vent opens and
closes.
Fan Speed
• Press switch to ensure all fan speeds work.
