29
Operation
Using Advanced Rack Timing
The Advanced Rack Timer allows you to create groups
of recipes with similar characteristics (cook temperature,
humidity level, etc.). The advance rack timer cook screen
lets you manage multiple recipes of the same group si-
multaneously on separate racks of the oven.
entering rack timer menus
1. From the MAIN MENU, press ADVANCED.
2. Select RACK TIMER.
seTTinG UP GRoUPs & ReCiPes
Creating a Recipe Group
NOTE: Up to 18 recipes can be assigned to a single
group. In order for recipes to be grouped to-
gether they must have the same cook mode, and
similar temperature settings.
1. To create a recipe group select the + key at the bot-
tom of the screen. This will bring you to the SETUP
GROUP screen.
2. Select NAME BAR to edit the group name. Use the
keypad to enter a group name. Press the right arrow
► key in the upper right hand corner of the screen to
save and return to the SETUP GROUP screen.
3. Select the camera icon in the IMAGE BAR to associ-
ate a picture with the group. Press OK to save the
selection and return to the SETUP GROUP screen.
4. Under RECIPES you can select existing recipes to
add to the group. Once a recipe has been selected a
green check mark will appear to the right indicating it
is part of the group. To remove a recipe, select it again
and the check mark will be removed. To add a new
recipe, see Creating a Recipe.
NOTE: The first selected recipe will define the set-
tings for the group. Recipes that have set-
tings incompatible with the group’s settings
will be grayed out.
5. When all desired recipes have been selected, press
the right arrow ► key in the top right corner to save
the group and return to the RACK TIMER MENU.
Name Bar
Image Bar
Create Recipe
Figure 21
editing a Group
1. In RACK TIMER MENU screen, press and hold the
group’s icon. A box will appear allowing you to edit or
delete the group.
