Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Bridge Menu
From the Bridge menu, you can view and edit bridge information such as the forwarding
database and the spanning tree status.
Forwarding Database
Displays the Forwarding Database table.
Discard/Aging Time Info
Displays information about the number of address entries that were learned but discarded
for reasons such as lack of memory or the entry's aging timer.
Spanning Tree Info
Displays spanning tree parameters such as priority and cost.
Statistics
Displays statistics about frames received/transmitted on the switch port.
Port Menu
From the Port menu, you can view and edit MIB information about the port.
Utilization
Displays the port's utilization information.
Interface Info
Displays port statistics such as the number of frames received and transmitted on the port,
bytes received and transmitted on the port, and port status.
Error Statistics
Displays error statistics.
Spanning Tree Info
Displays the port's spanning tree parameters.
MAU Info
Displays interface-related MAU information for the port.
MAU Negotiation Info
Displays the MAU's auto-negotiation settings and its status.
Enable
Enables the port.
Disable
Disables the port.
AT-9924T, AT-9924SP, AT-9924T/4SP
PN 613-50665-00 Rev B Page 225 of 277
