Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-8948
LED State Description
PWR 1 and
PWR 2 Green
Gray
Red
There is a power supply unit (PSU) in the PSU bay, and it is
supplying power to the switch.
There is a functioning Fan Only Module (FOM) in the PSU
bay.
Either:
- there is no PSU or FOM in the PSU bay, or
- a PSU is installed but has a power supply or fan fault or its
temperature has exceeded its recommended threshhold (75
degrees C), or
- an FOM is installed and a fan has failed.
Duplex Green
Orange
Gray
The port is operating at full duplex.
The port is operating at half duplex.
There is no link over the port.
Agent Menu
From the Agent menu, you can view and edit the system information for the switch, or log into
the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Power Supply Info
Displays information about the power supply.
Firmware Info
Displays a list of software releases installed on the switch.
File List
Displays a list of the files in the switch's file system.
Config File Name
Displays the file name of the start-up configuration file.
PN 613-50665-00 Rev B Page 198 of 277
