Chapter 6: Port Mirroring
88
Assigning a Destination Port
The destination port is the source port where the packets are copied. You
can only assign one destination port to the switch.
To assign a destination port, do the following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 24 on page 65.
2. From the Switching tab, hover over Port.
The Port tab is displayed.
3. From the Port tab, move the cursor to the right and select Mirroring
from the drop-down menu.
The Port Mirroring List page is displayed. See Figure 34 on page 87.
4. Select the pull-down menu next to the Destination Port field at the top
of the page.
5. Click on the port that you want to designate as the destination port.
You can only assign one destination port to a switch.
6. Click Apply.
The Edit option is removed from the port. This indicates the
destination port for the switch.
7. Click SAVE to save your changes to the startup configuration file.
