AT-8100 Series Version 2.2.5.0 Web Interface User’s Guide
259
MAC Address and mask: Enter a MAC source address
followed by a slash (/) and a mask if you are creating a MAC
ACL. The wildcard mask for MAC addresses must be either “0”
(zero) or “F” to indicate the parts of MAC address to filter. “F”
means anything; “0” (zero) means it has to match.
 Source Port— Select TCP or UDP from the pull-down menu and
enter a source port number as needed.
 Destination Port— Select TCP or UDP from the pull-down menu
and enter a source port number as needed.
 VLAN ID— Enter a VLAN ID. Use this field if you want the QoS
policy to filter tagged packets.
 CoS— Select a CoS value from the pull-down menu as needed.
Choose from 0 to 7.
 DSCP— Select a DSCP value from the pull-down menu as
needed. Choose from 0 to 63.
5. Click Create Classifier.
6. Click SAVE to save your changes to the startup configuration file.
