AVW200-series 2-Channel Vibrating Wire Spectrum Analyzer Modules
5. Device Configuration (DevConfig) Utility
Our Device Configuration (DevConfig) utility is bundled in Campbell
Scientific’s datalogger support software and can also be acquired, at no cost,
from: www.campbellsci.com/downloads . DevConfig 1.10 or greater is
required.
DevConfig supports AVW200 configuration, real-time data display, operating
system download, and vibrating wire spectrum analysis troubleshoot. You will
need to configure the AVW200 if you are using RF (PakBus), SDI-12, and RS-
232 (Terminal Commands). To use DevConfig, the AVW200 must be
connected to a PC and a power source.
(1) The default settings for the AVW200 may be used for many
applications.
(2) DevConfig has built-in help for each setting, which is
displayed at the bottom of the window.
5.1 Connecting to DevConfig
To connect to DevConfig, follow the procedure listed below:
1. Use the 19246 Power Cable (shipped with the AVW200) to connect the
AVW200 to the datalogger's 12 V supply or a regulated external power
source. When connecting the power leads, the ground lead should be
connected first and then the 12 V lead.
2. Connect the AVW200 to a COM port on your computer using the 10873
RS-232 cable (shipped with the AVW200).
3. Open DevConfig.
4. Under Device Type, click AVW200 Series (see FIGURE 5-1).
NOTES
25
