Altos 1100E Series User’s Guide 3-12
3.4.1 Floppy Drives
To configure the first floppy drive (drive A), highlight the Floppy Drive A
parameter. Press
or key to view the options, then select the appropriate
value.
Possible settings for the Floppy Drive parameters:
•
[ None ]
•
[360 KB, 5.25-inch]
•
[1.2 MB, 5.25-inch]
•
[720 KB, 3.5-inch]
•
[1.44 MB, 3.5-inch]
•
[2.88 MB, 3.5-inch]
Follow the same procedure to configure floppy drive B. Choose None if you do
not have a second floppy drive.
3.4.2 IDE Drives
Although IDE options are provided in the
system BIOS, IDE hard disk drives are
neither qualified nor supported in this server.
There are four IDE drive option items under the Disk Drives menu. Select the IDE
Primary Channel Master item (or the IDE Secondary Channel Master) if you want
to configure an IDE device set as master. Select the IDE Primary Channel Slave
item (or the IDE Secondary Channel Slave) if you want to configure an IDE device
set as slave.
