Chapter 1 – System Housing

1-9

1.5.2 5.25-inch Drives

You may install a CD-ROM, digital audio tape (DAT), hard disk, diskette drive or
any other 5.25-inch device into the drive bay.

To install 5.25-inch devices:

1. Open the front panel. See section 1.4 for more information on opening the

housing panel.

2. Detach the 5.25-inch drive frame (2 pieces) from the housing by removing two

screws. Keep the screws for later use.

3. Attach the drive frames to the 5.25-inch drive securing it with four screws as

shown below.
