Chapter 5 _______________________________________________________________ Maintenance
VAISALA ________________________________________________________________________ 49
Remote Probe Model
1. Unscrew the small sleeve that secures the probe in place at the end
of the probe cable and pull out the probe.
2. Replace the probe and screw the small sleeve back on, securing the
probe tightly in place.
1011-154
Figure 15 Removing the Humidity Probe (Remote Probe Model)
The following numbers refer to Figure 15 above:
1
= Probe cable
2 = Sleeve securing the probe to the cable
3 = HMP110 probe
1 2 3
