34
17
18
DINPlus(1)
DINMinus(1)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 1.
LVDS+ (P Side)
LVDS - (N Side)
25
26
DINPlus(2)
DINMinus(2)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 2.
LVDS+ (P Side)
LVDS - (N Side)
35
36
DINPlus(3)
DINMinus(3)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 3.
LVDS+ (P Side)
LVDS - (N Side)
47
48
DINPlus(4)
DINMinus(4)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 4.
LVDS+ (P Side)
LVDS - (N Side)
60
61
DINPlus(5)
DINMinus(5)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 5.
LVDS+ (P Side)
LVDS - (N Side)
68
69
DINPlus(6)
DINMinus(6)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 6.
LVDS+ (P Side)
LVDS - (N Side)
78
79
DINPlus(7)
DINMinus(7)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 7.
LVDS+ (P Side)
LVDS - (N Side)
88
89
DINPlus(8)
DINMinus(8)
In
Differential input pair, data part of Data-Strobe
SpaceWire port 8.
LVDS+ (P Side)
LVDS - (N Side)
19
20
SINPlus(1)
SINMinus(1)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 1.
LVDS+ (P Side)
LVDS - (N Side)
27
28
SINPlus(2)
SINMinus(2)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 2.
LVDS+ (P Side)
LVDS - (N Side)
37
38
SINPlus(3)
SINMinus(3)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 3.
LVDS+ (P Side)
LVDS - (N Side)
50
51
SINPlus(4)
SINMinus(4)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 4.
LVDS+ (P Side)
LVDS - (N Side)
62
63
SINPlus(5)
SINMinus(5)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 5.
LVDS+ (P Side)
LVDS - (N Side)
70
71
SINPlus(6)
SINMinus(6)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 6.
LVDS+ (P Side)
LVDS - (N Side)
80
81
SINPlus(7)
SINMinus(7)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 7.
LVDS+ (P Side)
LVDS - (N Side)
90
93
SINPlus(8)
SINMinus(8)
In
Differential input pair, strobe part of Data-Strobe
SpaceWire port 8.
LVDS+ (P Side)
LVDS - (N Side)
See section 10.2 for timing details.
