138 EXTOUTDATA10(8) PO44F External FIFO port 10 output data
139 EXTOUTEMPTYN10 PO44F External FIFO port 10 output empty
140 VSSA6 GND Ground
141 VDDA6 3V3 Power
142 EXTOUTREADN10 PIC External FIFO port 10 output read
143 EXTINDATA10(0) PIC External FIFO port 10 input data
144 EXTINDATA10(1) PIC External FIFO port 10 input data
145 EXTINDATA10(2) PIC External FIFO port 10 input data
146 EXTINDATA10(3) PIC External FIFO port 10 input data
147 EXTINDATA10(4) PIC External FIFO port 10 input data
148 EXTINDATA10(5) PIC External FIFO port 10 input data
149 EXTINDATA10(6) PIC External FIFO port 10 input data
150 EXTINDATA10(7) PIC External FIFO port 10 input data
151 EXTINDATA10(8) PIC External FIFO port 10 input data
152 EXTINFULLN10 PO44F External FIFO port 10 input full
153 EXTINWRITEN10 PIC External FIFO port 10 input wrte
154 VSSA7 GND Ground
155 VDDA7 3V3 Power
156 VSSB GND Ground
157 VDDB 3V3 Power
158 EXTTICKIN PIC Time-code tick in
159 EXTTIMEIN(0) PIC Time-code input
160 EXTTIMEIN(1) PIC Time-code input
161 EXTTIMEIN(2) PIC Time-code input
162 EXTTIMEIN(3) PIC Time-code input
163 EXTTIMEIN(4) PIC Time-code input
164 EXTTIMEIN(5) PIC Time-code input
165 EXTTIMEIN(6) PIC Time-code input
166 EXTTIMEIN(7) PIC Time-code input
167 SELEXTTIME PIC Time-code counter/input selection
168 TIMECTRRST PIC Time-code counter reset
169 EXTTICKOUT PO44F Time-code tick out
170 EXTTIMEOUT(0) PO44F Time-code output
171 EXTTIMEOUT(1) PO44F Time-code output
172 EXTTIMEOUT(2) PO44F Time-code output
173 EXTTIMEOUT(3) PO44F Time-code output
174 VSSB GND Ground
175 VDDB 3V3 Power
176 EXTTIMEOUT(4) PO44F Time-code output
177 EXTTIMEOUT(5) PO44F Time-code output
