11.2 ABSOLUTE MAXIMUM RATINGS
The absolute maximum ratings are listed in Table 11-2. For a detailed list of the maximum conditions
see [AD3].
Table 11-2 Absolute Maximum Ratings
Symbol Description Value Units
V
DD
Supply voltage range -0.5 to +4.0 V
V
IN
Input voltage range -0.5 to V
DD
+0.5 V
Input pin current
Signal pin -10 to +10 mA
I
IN
Power pin -60 to +60 mA
Lead temperature (soldering 10 sec) +300 °C
T
s
Storage temperature range -65 to +150 °C
T
J
Maximum junction temperature 175 °C
11.3 RELIABILITY INFORMATION
The information required for reliability analysis of the SpW-10X device has been collated and is
presented in Table 11-3.
Table 11-3 Reliabilty Information
Parameter Value
Technology CMOS 0.35 µm gate array
Complexity 371k Atmel MH1RT sites (approximately 285k gates)
Temperature Application dependent
Package QFP196 with 25 mil pin spacing
Environment Application dependent
Learning factor Established Atmel ASIC technology (MH1RT) for several years
