Ref.: UoD_SpW-10X_
UserManual
Issue: 3.4
SpW-10X
SpaceWire Router
User Manual Date: 11 th
July 2008
Preliminary
3
guidelines.
Section added on anomalies and
warnings.
Section added on Technical
Support.
20 th January 2008 Issue 3.1 Corrections and example
schematic improved. Steve Parkes
18 th April 2008 Issue 3.2 Explanation of non-blocking
cross bar switch added.
Cold sparing information added.
VCO bias resistor value
corrected (Section 5.7.4).
Tri-state mode changed to
deactivate mode.
Description for ‘time-code flag
mode bit’ added.
Reliability information added.
Anomaly 2 resolved.
Details and workarounds for
reset anomaly provided.
Steve Parkes
30 th April 2008 Issue 3.3 RD 3 changed.
Editorial corrections.
Correction to reset value of GAR
table entry.
Correction to support email
address.
Steve Parkes
11 th July Issue 3.4 Data after parity error anomaly
added. Steve Parkes
Detailed timing information
added.
DC characteristics updated.
Gerald Kempf
