15.17 ISSUE 1.1 TO ISSUE 1.2
Section Ref Change
6.3, 6.4, 6.5 Table 6-3,
Table 6-4,
Table 6-5 FPGA timing data added
15.18 ISSUE 1.0 TO ISSUE 1.1
Section Ref Change
5.1 Table 5-1 FEEDBDIV PLL clock settings section added
5.5 Table 5-5 STAT_MUX_OUT changed to multi function pin
5.6 Table 5-6 Power on reset signals mapped to STAT_MUX_OUT pins
8.1.6 Setting the data rate takes account of FEEDBDIV and transmit
clock control register setting TXDIV
8.3.5 Packet blocking correction does not cause disconnection of links.
