Atmel SpaceWire Router SpW-10X - Manual (Page 111)

Ref.: UoD_SpW-10X_
UserManual
Issue: 3.4
SpW-10X
SpaceWire Router
User Manual Date: 11 th
July 2008
Preliminary
111
14 Invalid Register
Address
‘0’ The invalid register address bit is set when an
unknown register address is given in the
command packet or a write is attempted to a
read only register R
15 Unsupported
protocol error
‘0’ The unsupported protocol error bit is set when
a command packet is received with a protocol
identifier which is not the RMAP protocol
identifier of 01h. R
16 Source logical
address error
‘0’ The source logical address error bit is set when
an invalid source logical address is received. R
17 Not used ‘0’ This bit in the register is not used. R
18 Cargo too large ‘0’ The RMAP command packet is too large R
19 Unused RMAP
command or packet
type
‘0’ The command code is an unused command
code or the packet type is invalid. R
23:20 Not Used - - -
