Use with AirLine Power at Passenger seat (with 4 pin

connection configuration

Use with Airline Power at Passenger SeatFigure 2

wit h 4-pin connection configurations)

AirSep’s FAA-approved FreeStyle enables you to use this

POC in-flight on most commercial airlines around the world.

Each airline establishes its own policy for FAA-approved POC

use, as well as the requirements for, and the availability of,

optionally allowing you to power your unit onboard the aircraft.

Aircraft-equipped passenger power may include one or more

of the following sources: an AC power outlet, a DC power

outlet similar to that typically found in an automobile, or a DC

power outlet with a 4-pin configuration.

If the specific airline on which you are traveling allows you to connect your POC

unit at a seat equipped with a 4-pin DC power configuration, take the following

steps:

1.

Make sure your power supply is securely connected to the FreeStyle inlet,

as shown in Figure 14.

2.

Connect the proper DC power cord end to the ACCESSORY DC IN inlet

on the power supply, as shown in Figure 19.

3.

Remove the tip of the DC connector by pressing on the tab to expose the

4-pin connector, as shown in Figure 20.

4.

Insert the 4-pin connection to the airline passenger DC outlet optionally

available at your seat.

5.

To operate the POC, press the FreeStyle [1], [2], or [3] setting on the

unit’s top panel, as determined by your prescription. To turn the unit off,

press the setting associated with the LED illuminated above it.

Figure 19
