What do the Steer Left, Steer Right, Center Wheels and Stop buttons do in the Line Acquisition
Mode?
1) Steer Left – Engages the ParaDyme System. If the vehicle is on the AB line, pressing the Steer
Left button moves the vehicle over to a new straight AB line approximately 6 to 12 inches left of
the current line. Figure 10 shows an example of the paths, which a vehicle will drive when
Steer Left is pressed.
2) Steer Right – Engages the ParaDyme System. If the vehicle is on the AB line, pressing the Steer
Left button moves the vehicle over to a new straight AB line approximately 6 to 12 inches right
of the current line. Figure 10 shows an example of the paths, which a vehicle will drive when
Steer Right is pressed.
3) Center Wheels – Engages the ParaDyme System. If the system is on the AB line, pressing Center
Wheels moves the current AB Line to the center of the graph.
4) Stop – Disengages the ParaDyme System, it can also be disengaged by turning the steering
wheel.
