Installing Add-On GPS Add-On GPS 3000/3050/3100
Ag Leader Technology
June 2001 Rev. 1 3000124 4
Step Action
NOTE: The mounting U-bracket that came with
yourPF3000 will not work with the Add-On GPS, you
must install the new bracket.
12 For U-brackets other than window mount brackets:
• Remove existing U-bracket and retain fasteners.
• Install new U-bracket with fasteners from old bracket
• Attach PF3000 to the U-bracket and attach 25-pin
connector.
13 For window mounted brackets:
• Remove window mounting bracket and discard.
• Completely remove old adhesive from window.
Updating
Operating
Program The version of operating program that the monitor is using is displayed
when you turn on the PF3000. You MUST have the 3.1 or later
operating program for the PF3000 to use the Add-On GPS3000/3100.
For the Add-On GPS 3050 you must have version 3.13 operating system
installed. To determine if version 3.13 is installed, press the MENU key
until DIAG is displayed. Press the SYSTEM key. Look on the Program
version line to determine the current program.
If you do not have the 3.1 or 3.13 or later version, contact Ag Leader
Technology at 515-232-5363 to obtain an update.
Perform the following steps to install the new operating program:
Step Action
1 Using a computer card reader, copy the file “upgrade.pld”
to the memory card. Delete all other files off the card.
2 Install the card in the monitor and turn on the monitor.
3 The monitor will automatically detect a new operating
program on the card. The monitor will display the version
number of the current program and new program. Press
the ACCEPT key to install the new version.
4 The monitor will erase the old program and install the
new program.
5 Check some of the field and load information and settings
to double check that the new programs is operating
correctly
