General Instructions Add-On GPS 3000/3050/3100
Ag Leader Technology
June 2001 Rev. 1 3000124 10
Overview
General
Information
The Add-On GPS 3000/3050/3100 requires no initial setup to begin
fieldwork. The PF3000 will display a “D” or “G” on the top right hand
corner of the display to indicate a GPS signal. A “D” indicates that you
have a differential signal. A “G” indicates that you have a GPS signal
and your GPS receiver is tracking four or more satellites. A lower case
“g” indicates that you have a GPS signal but your GPS receiver is
tracking only three satellites. Your GPS receiver must track four or more
satellites to get an elevation reading. You may wish to use the GPS to
show your ground speed, which requires changing the ground speed
sensor settings. Refer to Primary and Secondary Speed Sensor under
Vehicle Setup in the PF3000 Operator’s manual for instructions.
NOTE: WAAS is an optional feature now available for use with
the Add-On GPS. Contact Ag Leader Technical Support at 515-
232-5363 for more information on this capability.
The following provides information to change factory settings on the
Add-On GPS 3000/3050/3100:
Beacon Selection The settings for beacon selection are Auto range, Auto Power and
Manual.
• Auto Range: This is the default setting. In this setting the receiver
keeps a record of the closest three beacons within the receivers
range. It then selects a beacon based on the ranking of the beacon
in memory.
• Auto Power: The receiver keeps a record of the three strongest
beacons in its range. It then selects a beacon based on the ranking
of the available beacons.
• Manual: Allows you to input frequencies for two beacons.
To change Beacon Selection complete the following steps:
Step Action
1 Press Menu key on PF3000 until SETUP is displayed and
press SETUP.
2 Press bottom left or right arrow key until GPS is
displayed and press GPS key.
