General Instructions Add-On GPS 3000/3050/3100
Ag Leader Technology
June 2001 Rev. 1 3000124 24
NMEA Messages The Add-On GPS unit uses Trimble TSIP to provide position
information to the PF3000. This means that NMEA messages (Figure
18) do not need to be set and will not be displayed on the NMEA
diagnostic screen.
NMEA MESSAGES
GGA ON
GLL OFF
VTG ON
GSV OFF
GSA OFF
ZDA OFF
ALM OFF
RMC OFF
MSS ON
EDIT EXIT
Figure 18. NMEA Messages Screen
GPS
Output/Input
The GPS Output/Input screen (Figure 19) requires no adjustment
at this time. This screen will be used for future options for the
AUX Port of the GPS.
GPS OUTPUT/INPUT SETUP
Output rate
1Hz
Port AUX
Output baud rate 4800
Output type NMEA
Input baud rate 9600
Input type TSIP
SUMMARY CAL SETUP DIAG
Figure 19. GPS Output/Input Setup Screen
***
