Add-On GPS 3000/3050/3100 Antenna Instructions
Ag Leader Technology
June 2001 Rev. 1 3000124 9
Routing the Cable
to the Cab You will need the following parts and tools to route the coaxial cable into
the combine:
• Bulkhead connector (threaded on both ends)
• ½ in. drill bit
• Power drill
Follow these steps to route cable to the cab:
Step Action
1 Find a place on the right side or bottom of the cab to route
coaxial cable into cab (the point of entry is up to you).
IMPORTANT: Do NOT route cable through a door or
window because this will crimp the cable and ruin it.
2 Find a sit to drill where you will not drill into any cabling
or hoes; then drill a hole with the 1/2 in. bit.
NOTE: Make sure before you drill that:
•
The coaxial cable will reach to the site you have
chosen.
•
That you do not bend the cable at a 90-degree
angle.
3 Thread bulkhead connector through hole, so that the
threaded end to which you attach the lock washer and jam
nut is inside cab.
NOTE: For JD9000 series combines, a rubber grommet is
included to mount the bulkhead connector through cab
wall plate. Use auxiliary hole in the plate or drill a new
hole if the auxiliary hole is in use.
4 Attach the coaxial cable from the antenna to the outside
end of the connector.
***
